PZL
SWIDNIK
PZL
- SWIDNIK
W-3A |
|
Este helicóptero es un diseño enteramente nuevo bajo el equipo del diseñador Stanislaw Kaminski, similar al Kania externamente pero tiene una capacidad de dos pilotos y 12 pasajeros. Fue entregado a las Fuerzas Militares Polacas (40), a Korea (3) y a la Policia Aduanera de Alemania (6). El 31 de mayo de 1993 fue el primer helicóptero del antiguo bloque del este en obtener el certificado de la FAA. |
|
This helicopter is an
entirely new design by PZL's design team under Stanislaw Kaminski, and while it
is externally similar to the Kania it is a larger helicopter with
capacity for two crew and twelve passengers. Aimed at the full range of civil
and military applications, the Sokol has been delivered in quantity to the
Polish military forces (40 examples) and to Myanmar (12), Korea (3) and the
German Border Police (6). On 31 May 1993, it became the first Eastern bloc
helicopter to be awarded FAA certification
|
|
Characteristics |
Information |
Characteristics |
Information |
First
Flight Primer Vuelo |
1979 |
Engine Motor |
2 |
Seating
Capacity Plazas |
2 / 12 |
Power Potencia |
900 SHP each |
Empty
Weight Peso Vacío |
8487 Lb |
Hover
Ceiling O.G.E. Estacionario O.G.E |
6232 Ft |
Maximum
Weight Peso Máximo |
14110 Lb |
Hover
Ceiling I.G.E. Estacionario I.G.E |
9906 Ft |
Vel.
Cruise Vel. crucero |
130 Kts |
Service
Ceiling Techo de Servicio |
Ft |
V.N.E. V.N.E |
140 Kts |
Maximum
Range (Std) Alcance (Std) |
428 NM |
