EUROCOPTER AS-532 UC AC COUGAR

The AS 532 UC is the "short" version of the AS 532 UL. It has the same dynamic assemblies and the same engines, but a smaller cabin and therefore a bigger payload capability. It can carry up to 21 commandos. When fitted with the appropriate optional systems, the AS 532 UL and the AS 532 UC are capable of performing SAR missions. They can also be equipped with 7.62 mm machine guns.

AS 532 AC COUGAR: The AS 532 AC is the armed version of the AS 532 UC.

Maximum useful load (including mission fuel) UC: 10,296 lb
AC: 10,250 lb

Characteristics Características	Information Información	Characteristics Características	Information Información
First Flight Primer Vuelo	19??	Engine Motor	2 Turbomeca Makila 1 A1
Seating Capacity Plazas	2 / 21	Power Potencia	1877 shp each 1819 shp Cont
Empty Weight Peso Vacío		Hover Ceiling O.G.E. Estacionario O.G.E
Maximum Weight Peso Máximo	19840 Lbs	Hover Ceiling I.G.E. Estacionario I.G.E
Vel. Cruise Vel. crucero	139 Kts	Service Ceiling Techo de Servicio
V.N.E. V.N.E	Kts	Maximum Range (Std) Alcance (Std)	528 NM
