Technical Specifications Processor and memory � 400MHz or 500MHz PowerPC G3 processor � 1MB backside level 2 cache on processor module; 160MHz or 200MHz dedicated 64-bit backside bus � 100MHz system bus � Integrated floating-point unit and 64K on-chip level 1 cache (32K data and 32K instruction) � 64MB or 128MB of PC100 SDRAM (3.3-volt, unbuffered, low-power, 64-bit-wide, 144-pin, running at 100MHz); two SO-DIMM slots support up to 512MB Storage � Internal 6GB, 12GB, or 18GB Ultra ATA/66 hard disk drive (18GB drive available in build-to-order computers) � Hot-swappable expansion bay for DVD-ROM drive or third-party storage solutions such as Zip, SuperDisk, and hard disk drives � 6x-speed (maximum) DVD-ROM drive for use in expansion bay; reads DVD-ROM, DVD-Video, and DVD-RAM discs; reads CD-ROM discs at up to 24x speed Communications � Built-in 10/100BASE-T Ethernet (RJ-45 connector) � Built-in 56K V.90 modem (RJ-11 connector)* � Optional 11-Mbps AirPort wireless networking card (IEEE 802.11 DSSS compliant) � Infrared technology port (4-Mbps IrDA) Security � Kensington cable lock slot � Keyboard lock |
|
Expansion � Two 400-Mbps FireWire (IEEE 1394) ports � Two 12-Mbps Universal Serial Bus (USB) ports � One PC Card and CardBus slot � Support for one Type I or Type II PC Card or CardBus card � Support for a Zoom Video PC Card Video and graphics support � 8MB of SDRAM video memory supports millions of colors on external displays up to 21 inches � Built-in 2D/3D graphics acceleration through an integrated ATI RAGE Mobility 128 video controller with AGP 2X � 24-bit video output port (VGA-style connector) � S-video output port Display � 14.1-inch (diagonal) built-in TFT XGA active-matrix display � Supports millions of colors at 1024� by 768-pixel resolution � Supports resolution scaling to 640� by 480-pixel or 800� by 600-pixel resolution Sound � 16-bit CD-quality stereo input/output � Two built-in stereo speakers � Internal omnidirectional microphone Battery and power � 50-watt-hour lithium-ion battery �Provides up to 5 hours with one battery and up to 10 hours with two batteries, depending on configuration and usage � Power adapter port |
|
Keyboard � Built-in full-size keyboard with 76 (U.S.) or 77 (ISO) keys, including 12 function keys, 4 arrow keys (inverted �T� arrangement), and embedded keypad Apple trackpad � Solid-state Apple trackpad provides precise cursor control; supports tap, double-tap, and drag capabilities Electrical requirements � Line voltage: 100V to 240V AC � Frequency: 50 to 60Hz Environmental requirements � Operating temperature: 50� to 95� F (10� to 35� C) � Storage temperature: -40� to 116� F (-47� to 47� C) � Relative humidity: 20% to 80% noncondensing � Maximum operating altitude: 10,000 feet (3,048 m) � Maximum storage altitude: 15,000 feet (4,572 m) � Maximum shipping altitude: 35,000 feet (10,688 m) Size and weight � Width: 10.4 inches (26.4 cm) � Height: 12.7 inches (32.3 cm) � Depth: 1.7 inches (4.3 cm) � Weight: 5.7 pounds (2.6 kg) with battery and weight-saving module installed; 6.1 pounds (2.8 kg) with DVD-ROM drive and battery installed (weight varies by configuration and manufacturing process) *Actual modem speeds lower; speed depends on connection rate and other factors. |
|
