Educational use only . To make this device is illegal in almost every countries of the world , or it is a Class3 weapon. ; Ezt az fegyvert elkesziteni a vilag majdnem minden orszagaban torvenybe utkozik
Nemreg talalkoztam egy , a volt Jugoszlaviabol szarmazo tollpisztollyal
, amely hasonlo kialakitasu volt , mint az itt bemutatasra kerulo . Kicsit
foloslegesen bonyolult volt az eloallitasa , ugyhogy leegyszerusitettem
a rola keszulo rajzon. Az eredetihez 4mm-es potcso is volt , es egy
szelesedo toldattal 15mm-es jelzoraketat is lehetett loni vaktolteny
segitsegevel.
A ketyere legnagyobb elonye hogy a legbenabb esztergalyos is meg tudja
csinalni egy ora alatt , a rugo kivetelevel. A pisztoly anyaganak
barmilyen acel megfelel ,
az alkalmazott kis teljesitmenyu loszer miatt . Az alkatreszeket menettel
illesszuk egymasba , ha megnezed a rajzot , akkor lathato , hogy tulzott
precizitas sem szukseges . A kozolt meretektol felfele nyugodtan el lehet ,
terni , mert a kozoltekkel garantaltan biztonsagosan fog mukodni.
Az utoszeget legegyszerubben a dugattyubol lehet kireszelni .
.22 Shortnal erosebb loszert a "nyitott zarszerkezet" es a kis
suly miatt nem ajanlok. Igazabol a 6mm-es flobert loszerekkel mukodik
kenyelmesen.
I recently met with a pen gun what was manufactured in the former
Yugoslavia . That was similar to the shown one , but more difficult to make.
I simplified its mechanism and drew it .The original model has
replacement barrel for 4mm rimfire , and another attachment for 15mm flare shooting
device with blanks.
The biggest advantage of this device , that , an average turner can make it
in an hour , except the spring. The material of the gun can be every kind of
steel, `cose the fired cartridge is low powered. If you look the image, you see
, that the high level of precision isn`t necessary.The parts of the gun must be
fit into each other via screw-threads .
(The sizes are in millimeter. 25.4mm=1 inch )
The sizes on the image are changeable , but with these the gun operate safely.
The firing pin must be rasped from the piston. I do not recommend to use the gun with
more powerful cartridges than .22Short , thanks to it`s light weight , and "open
bolt ". The pengun really comfortable with use of 6mm Flobert (BB Caps).
