| Engine |
|
Type |
Light-alloy 90 degree V6, overhead valves with chain driven overhead camshafts |
| Displacement |
2.85 liters (174 cubic inches) |
| Bore & stroke |
91x73mm (3.58 x 2.87 inches) |
| Compression |
8.8:1 |
| Block type |
Light-alloy with cast iron cylinder liners |
| Cyl. heads |
Light-alloy, cross-flow, hemi-chambers |
| Cooling system |
Water/Ethylene Glycol, radiator forward with twin thermostatically controlled fans |
| Fuel system |
C.I.S. Fuel-injection, Bosch K-Jetronic |
| Ignition system |
Breakerless, electronic/Bosch |
| Emission control |
Lambda Sond/catalytic, unleaded fuel |
| Drivetrain |
|
Engine location |
Rear-mounted |
| Transmission |
5 speed, fully synchronized or 3 speed auto |
| Final drive |
Trans-axle/double universal half-shafts, ratio 3.44:1 |
| Body |
|
Construction |
Structural-composite single piece underbody with corrosion free outer body panels; 304 stainless steel |
| Chassis |
|
Construction |
Corrosion protected steel backbone frame with fore and aft wishbones, supporting cross members and 4-wheel independent suspension; controlled impact crush |
| Suspension |
|
Front |
Compliant, unequal length wishbones and coil boxed spring, telescopic shock absorbers and anti-roll bar |
| Rear |
Compliant, diagonal trailing radius arms with upper and lower links, coil spring with telescopic shock absorbers |
| Steering |
|
Type |
Rack and pinion |
| Min. Turn |
5.334 meters (17.5 feet) |
| Turning circle |
10.67 meters, curb to curb (35 feet) |
| Wheel turns |
2.65 (lock to lock) |
| Brakes |
|
Type |
Power assisted discs, front and rear |
| Disc diameter |
254mm (10 inches) front, 267mm (10.5 inches) rear |
| Parking brake |
Mechanical, separate, self adjusting, acting on rear discs |
| Wheels/Tires |
|
Wheels |
Cast light-alloy, 357mm x 152mm (14 inches x 6 inches) front; 381mm x 203mm (15 inches x 8 inches) rear |
| Tires |
Goodyear NCT steel belted radial; 195/60HR-14 front; 235/60HR-15 rear |
| Dimensions and Capacities |
|
Wheelbase |
2408mm (94.8 inches) |
| Track |
1590mm (62.6 inches) front; 1588mm (62.5 inches) rear |
| Length overall |
4267mm (168.0 inches) |
| Width overall |
1988mm (78.3 inches) |
| Height |
1140mm (44.88 inches) |
| Weight |
1233kg (2712 pounds) with full tank |
| Fuel Capacity |
51.6 liters (13.2 gallons) |
| Luggage space |
396 liters (14 cubic feet) |
| Standard Features |
|
Stainless steel body panels |
| Counter-balanced gull-wing doors |
| Leather seats and trim |
| Air conditioning |
| Multi-speaker, high output stereo system with cassette |
| Power windows |
| Tilt and telescopic steering wheel |
| Dual electric remote side mirrors |
| Full instrumentation |
| Central door locking system |
| Tinted glass |
| Body side moldings |
| Intermittent windshield wipers |
| Sylvania halogen headlamps |
| Engine/luggage compartment lights |
| Interior hood and engine compartment release |
| Electric rear window defogger |
| Locking gas cap |
| |
