Price: (est) US$66,045
| Selected Standard Features |
|
| Optional Equipment |
|
| Performance (source: Car & Driver) | |
| Acceleration | |
| Zero to 30 mph | 1.8 |
| 40 mph | 2.4 |
| 50 mph | 3.2 |
| 60 mph | 4.1 |
| 70 mph | 5.1 |
| 80 mph | 6.5 |
| 90 mph | 8.1 |
| 100 mph | 9.8 |
| 110 mph | 11.9 |
| 120 mph | 14.2 |
| 130 mph | 16.9 |
| 140 mph | 20.3 |
| 150 mph | 29.0 |
| Street Start, 5-60 mph | 4.6 |
| Top-gear passing time, 30-50 mph | 9.3 |
| 50 - 70 mph | 9.1 |
| Standing 1/4 Mile | 12.6 sec @ 113 mph |
| Top Speed (drag limited) | 173 |
| Braking | |
| 70 - 0 mph @ impending lockup | 163 ft. |
| Modulation | excellent (scale: poor, good, fair, excellent) |
| Fade | none (scale: none, light, moderate, heavy) |
| Front-rear balance | good (scale: poor, fair, good) |
| Handling | |
| Roadholding, 300-ft-dia skidpad | 0.97 g |
| Understeer | moderate (scale: minimal, moderate, excessive) |
| Fuel Economy | |
| EPA city driving | 13 mpg |
| EPA highway driving | 21 mpg |
| Engine | |
| Number of cylinders | 10 |
| Power | 415 bhp (309kW) @ 5200 rpm |
| Displacement | 488 cu. in. (7900cc) |
| Bore | 4.00 in. (101.6 mm.) |
| Stroke | 3.88 in. (98.5 mm.) |
| Torque | 488 Foot Pounds at 3600 RPM |
| Compression Ratio | 9.1:1 |
| Construction | 90-degree V-10 cast aluminum block with cast iron cylinder liners, aluminum heads and crankcase |
| Recommended Fuel | Premium unleaded |
| EPA Fuel economy (mpg city/hwy.) | 12/21 (1995 data) |
| Emissions Controls | Three-way catalytic converters with dual oxygen sensors, one per side feedback fuel-air ratio control |
| Fuel Requirement | Unleaded Premium, 91 Octane |
| Drivetrain | |
| Transmission | Six-speed manual, fully synchronized, with electronic 1 - 4 skip-shift and reverse lockout mechanims. |
| Gear Ratios | |
| First | 2.66:1 |
| Second | 1.78:1 |
| Third | 1.30:1 |
| Fourth | 1.00:1 |
| Fifth | 0.74:1 |
| Sixth | 0.50:1 |
| Effective Final Drive | 3.07:1 |
| Overall Top Gear | 1.54:1 |
| Electronics | |
| Battery | 770 cold cranking amps |
| Alternator | 50/120 amps |
| Body Specifications | |
| Body | Resin transfer molded composite body |
| Frame | Tubular space frame with separate cowl structure |
| Suspension | |
| Front | Independant with unequal length upper and lower control arms, coil-over-shock units. |
| Rear | Independant with unequal length upper arms with separate toe link, coil-over-shock units. |
| Front Stabilizer Bar | 1.06 in/27 mm (tubular) |
| Rear Stabilizer Bar | 0.86 in/22 mm (tubular) |
| Shock Absorbers | Double-acting hydraulic, low pressure, gas charged, rebound adjustable |
| Coil Springs | 2.5" I.D. micro-grain alloy |
| Dimensions | |
| Overall Length | 175.11 in. (4448 mm) |
| Maximum Width | 75.74 in. (1924 mm) at rear wheel lip |
| Overall Height | 43.95 in. at windshield frame |
| Track: Front | 59.6 in. (1514 mm) |
| Track: Rear | 60.6 in. (1538 mm) |
| Wheelbase | 96.2 in. (2444 mm) |
| Ground Clearance | 5.0 in. with two passengers |
| Luggage Capacity | 3.6 cu. ft. (101.9L) |
| Curb Weight | 3445 lbs (1588kg) |
| Weight Distribution (front/rear) | 50/50 |
| Frontal Area | 19.3 sq. ft. (top off) |
| Drag Coefficient | 0.55 (top off) |
| Steering | |
| Type | Power rack-and-pinion |
| Ratio | 16.7:1 |
| Turns (lock-to-lock) | 2.4 |
| Turning diameter | 40.5 ft. |
| Alignment Specifications | |
| Caster | Front: +5.75 degrees Rear: -5.75 degrees |
| Camber | Front: -0.4 degrees Rear: -0.4 degrees |
| Toe | Front: +0.1 degrees toe-in Rear: +0.1 degrees toe-in |
| Wheels and Tires | |
| Wheel Type | Semi-forged aluminum |
| Front Wheel Size | 10" x 17" |
| Rear Wheel Size | 13" x 17" |
| Spare Wheel Size | 4" x 16" |
| Tire Type | Michelin Pilot MXX3 (directional) |
| Front Tire Size | P275/40ZR17 |
| Rear Tire Size | P335/35ZR17 |
| Rev/Mile (rear) | 804 |
| Fluid Capacities | |
| Fuel (approx.) | 19 Gal. (72L) |
| Engine Oil | 11 qts. (10.4 L) |
| Cooling System | 18.3 qts. (17.0L) |
| Brake System | |
| Type | Front and rear power-assisted disk, dual hydraulic, front/rear split |
| Front Brake Discs | 13" x 1.26" vented |
| Rear Brake Discs | 13" x 0.87" vented |
| Front Calipers | Four opposed, four fixed pistons |
| Rear Calipers | Single piston, slider-type |
| Power Assist Type | Tandem diaphragm vacuum w/zero lost travel |
| Swept Area | Front: 304.7 sq. in. Rear: 253 sq. in. |
| Accomodations | |
| Seating Capacity, F/R | 2/0 |
| Front Leg Room - Max. | 42.6 (1081.5) |
| Front Shoulder Room | 53.8 |
| Seat Travel | 6.0 (152) |
| Recliner Range | 11 |
| Seat Adjustments - Driver | Horizontal, recliner, inflatable lumbar support |
| - Passenger | Horizontal, recliner, inflatable lumbar support |
| Restraints - Front | 3-point passive belt - w/door mounted retractor |
| Instrumentation | |
| Instruments | Analog Speedometer, odometer, trip odometer, tachometer, voltmeter, oil pressure, coolant temperature, fuel. |
| Warning Lamps | 2-3 shift lockout, brake charging system, check engine, coolant level, coolant overheat, high beam, low oil pressure, seat belts,turn signals, security alarm. |
