Whell arrangement | 0-6-0T | Heating Surface(ft²) | 876 |
Loco. Weight in Working Order(lbs) | 100650 | Loading Capacity of Water(gallons) | 1200 |
Loading Capacity of Fuel(gallons) | 300 | ||
Height of Boiler Center | 9' | ||
Max Axle Weight(lbs) | 33550 | ||
Height | 14'10½" | ||
Cylinder Dimensions | 16½"X26" | Length of Locomotive | 29'6" |
Boiler Pressure(lb/in²) | 210 | ||
Grate Area (ft²) | 19.4 |
